♦ Description:
1. Integrative design for aluminum housing, with good heat sinking
and longer lifespan
2. Using COB LED as light source, bad light ;
3. LED Downlight convenient disassembly maintenance, saving
maintenance costs;
4. glass surface cover, anti-glare;
5. power supply isolated constant current power supply, security
and stability.
6. Light source: 1pcs 30W COB LED.
7. Housing materials:Al + glass cover.
8. CCT: 2700-6500K.
♦ Main Features:
1. Cree/Epistar/Bridgelux/ COB LED Chip inside,High light
output>100Lm/W,High CRI>80;Energy saving up to 80%.
2. Patent DIWL Lens,Anti-glare Diamond quality;
3. Absolutely unique mold, make your lighting special and
fantastic;
4. World Top class LED driver-Meanwell Types Inside;
5. 3 Years warranty , leave no worries about quality, enjoy the
qualified green life.
6. Operational condition:Temperature -40°C~60°C Humidity:10%~90%RH.
♦ Product Parameters:
| Model No: | GDL-COB LED Down Light-30W |
| Power(W): | 30W |
| LED Chips: | Epistar / Bridgelux / Samsung |
| Input Voltage(V): | 85-265V/50-60HZ |
| Lumens(Lm): | 100-120LM/W |
| Illuminance Efficiency: | >85% |
| Color Temperature(K): | | 3000K-3500K |
| 4000K-5000K |
| 5000K-6500K |
| Power Factor: | >0.9 |
| Life-span: | >50000Hours |
| Working Temperature: | -40°C~ +55°C |
| Beam Angle: | 120° |
| Color Rendering Index: | >80 |
| Lamp Shell Color: | Silver&White |
| Product Size: | 226*226*65mm, |
| Material: | Alu+PC |
| Certificate: | IEC&CE&RoHs |
| Warranty: | 3 years |
| LED Q'ty: | 1pcs |
| Installation: | Embedded/Surface / Receessed |
♦ Product Show
♦ Applications:
1. Apply to houses, hotels, restaurants, schools, shopping malls
etc., can be universally used for decorative lighting of various
commercial place.
2. Apply to office, meeting room, exhibition hall, can be used for
interior lighting in the office building.
3. Apply to residential lighting such as aisle, washroom, corridor,
storehouse, etc.
4. Apply to shop window, painting displaying, artwork performance,
etc., can be used for partial close-up lighting.
5. Apply to cafe, bar etc., can be used for entertainment lighting.
6. Apply to billboards,highway.
7. Apply to stadums,parking lot.
8. Apply to Factories,kitchen,display
